Jiangsu Shuoyun Petrochemical Equipment Co., Ltd.

  I. Working Principle

  The drum flaker implements a cooling crystallization process. The molten material in the feed pan contacts the cooled rotating drum and forms a material film on the drum surface. Heat exchange between the film and drum wall cools and crystallizes the material film. The crystallized film is scraped off by a scraper to obtain flaky products.

  Drum drying is a continuous operation process. By means of heat transfer through a rotating drum, materials attached to the outer drum wall or strip materials are heated and dried.

II. Equipment Features

  Performance reaches the level of foreign equipment of the same era

  Side scrapers are equipped to prevent material accumulation at drum ends

  Compact equipment structure with small footprint

  Half-pipe jacketed feed pan, safe and reliable

  Atomization cooling for excellent cooling effect

  Stepless speed regulation; drum rotation speed adjustable

  High-precision rotating drum

  Wide application range, simple and flexible operation

  Multiple sets of scrapers for flexible adjustment

  Multi-functional: available for both flaking and drying

  III. Application Scope

  1. Flaking   2. Drying

  IV. Equipment Specifications and Main Parameters
